Venkraft Paper Mills (P) Ltd. > UNIT - 1 Products > Test Liner / Kraft Paper




  • High Strenght Kraft Paper
  • Basis Weights - 50 to 180 GSM


  At a level of almost 100,000 tons annually, Venkraft is one of the largest producers of containerboard/kraft paper in Southern India. Kraft Paper sometimes referred to as linerboard or medium, is the paper that is used for making corrugated boxes and displays. Our Four-driner Combined Paper Machine has all the requisite equipments to manufacture the following.

Machine Finished Kraft Paper
GSM Range 50 to 180 grams/m2
Machine Deckle 275 to 285 cms. / 108 to 112 inches
Colour Shades Natural, Golden Yellow
BF Range 18 to 24 BF

 From rugged boxes for protecting fruit in transit, to those in direct contact with fast food, or from safe shipping of heavy duty electronic goods to luxury products where high-quality printing is essential, Venkraft has an innovative, cost-effective Test liner solution. Applications include standard boxes, die-cut boxes and trays as well as POS-displays and corrugated sheets.

USES:





Variety /
Quality		 Burst Factor
(BF)		 Substance
grams/m2(GSM)		 Ring Crush Test (RCT)
in Cross Direction (CD)
kN-m kgf/152 mm
Eco - Test Liner 24 120 0.96 to 1.00 15.0 to 15.6
150 1.27 to 1.28 19.8 to 20.0
180 1.52 to 1.54 23.7 to 24.0
Test Liner 28 120 0.98 to 1.08 15.3 to 16.8
150 1.28 to 1.30 20.0 to 20.3
180 1.56 to 1.60 24.3 to 25.0
Tolerance: ± 3% Tolerance: ± 5%


Parameter Unit Value
Stretch %MM 3.0-4.0
Cobb Top GSM 40 - 45
Cobb Bottom GSM 45 - 50
Moisture % 6.0-7.0%
Tolerance:± 3%

 Please note:
  1. The tolerances are based upon 95% confidence limit and on laboratory results of random samples from mill.
  2. The specifications are subject to change without any prior notice.
  3. Moisture is measured on oven dry method.
  4. Paper board Machine Deckle: 275 cms to 285 cms.
  5. conversion factors :
        kgf/cm x 0.980665 = 1 kN/m; kgf/cm= (1/0.980665) kN/m;
        kgf/15.2cm= (15.2/0.980665) kN/m = 15.499 kN/m;
        kN/m= (1/15.499) kgf/152mm = 0.0645 kgf/152mm.
